Description
Description
The pair of jaws is suitable for 2-jaw universal pullers "Techno". The robust jaws guarantee particularly safe removal of bearings, gears, and discs.
Application
For 2-jaw universal puller "Techno"Article features
 Reach external extraction [mm/inch] |
 Overall length [mm/inch] |
 Total jaw thickness (L+1 mm) (jaw distance to base surface) [mm/inch] |
 Overall jaw's hooked claw depth (overall claw depth H) [mm/inch] |
 jaw's hooked claw width (jaw spread J) [mm/inch] |
 Usable jaw's hooked claw reach (usable claw reach O) [mm/inch] |
 Jaw's hooked claw thickness at the tip (claw thickness K) [mm/inch] |
Gross weight [kg/lb] |
 Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|---|
|
250 mm / 9 13/16 in |
306 mm / 12 1/16 in |
18 mm / 11/16 in |
35 mm / 1 3/8 in |
20 mm / 13/16 in |
14 mm / 9/16 in |
9 mm / 3/8 in |
2,9 kg / 6.395 |
2,74 |
