Description
Description
The pulling hook is suitable for 3-jaw pullers of series 12. The robust pulling hooks guarantee particularly safe pulling of bearings, gears, and discs.
Application
For 3-jaw pullers of series 12Article features
 Reach external extraction [mm/inch] |
 Overall length [mm/inch] |
 Total jaw thickness (L+1 mm) (jaw distance to base surface) [mm/inch] |
 Overall jaw's hooked claw depth (overall claw depth H) [mm/inch] |
 jaw's hooked claw width (jaw spread J) [mm/inch] |
 Usable jaw's hooked claw reach (usable claw reach O) [mm/inch] |
 Jaw's hooked claw thickness at the tip (claw thickness K) [mm/inch] |
Gross weight [kg/lb] |
 Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|---|
|
300 mm / 11 13/16 in |
554 mm / 21 13/16 in |
20 mm / 13/16 in |
70 mm / 2 3/4 in |
28 mm / 1 1/8 in |
22 mm / 7/8 in |
4 mm / 3/16 in |
5,3 kg / 11.687 |
6,94 |
