Description
Description
The jaw hook is suitable for 3-jaw universal pullers with auto-snap of series 483. The spring effect and the slim design allow pulling at hard-to-reach places.
Application
For 3-jaw universal pullers with auto-snap of the series 483Article features
![]() Reach external extraction [mm/inch] |
![]() Overall length [mm/inch] |
![]() Total jaw thickness (L+1 mm) (jaw distance to base surface) [mm/inch] |
![]() Overall jaw's hooked claw depth (overall claw depth H) [mm/inch] |
![]() jaw's hooked claw width (jaw spread J) [mm/inch] |
![]() Usable jaw's hooked claw reach (usable claw reach O) [mm/inch] |
![]() Jaw's hooked claw thickness at the tip (claw thickness K) [mm/inch] |
Gross weight [kg/lb] |
![]() Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|---|
|
90 mm / 3 9/16 in |
118 mm / 4 5/8 in |
5 mm / 3/16 in |
18 mm / 11/16 in |
8 mm / 5/16 in |
8 mm / 5/16 in |
2,5 mm / 1/8 in |
0,59 kg / 1.301 |
0,08 |
