Description
Description
The 14-piece universal puller set with quick adjustment, hydraulic spindle and extensions of the K-20-1-2+B series is used for 2-jaw pulling of normal and especially tight-fitting bearings, gears, disks, etc. in crafts, industry, and workshops. The series impresses with its versatile construction possibilities. The "6 in 1" kit allows the assembly of 6 different puller models by combining hydraulics, jaws, and extensions.
Application
For the extraction of normal and particularly well-seated bearings, gears, discs, etc. in craft, industry, and workshop.Article features
 Spread external extraction (min. - max.) [mm/inch] |
 reach (min. - max.) [mm/inch] |
 spread internal extraction (min. - max.) [mm/inch] |
Max. tensile force [kN] |
 Max. tension force [t/US t. sh.] |
Gross weight [kg/lb] |
 Consists of |
Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|
|
0 - 160 mm / 0 - 6 5/16 in |
0 - 300 mm / 0 - 11 13/16 in |
100 - 220 mm / 3 15/16 - 8 11/16 in |
100 kN |
10 t / 11.02 |
0,3 kg / 0.662 |
20-1+, 20-2+, 8-0-621, 600-17, 1-192-P, 2-302-P | 0.01 |
