Description
Very compact 21-piece tool set. One Kraftform 815/1 handle, suitable for mounting bits with 1/4" external hexagon drive, one 8011 Zyklop Mini 4 bit ratchet (1/4"), also suitable for 1/4" sockets using the included 870/1 adapter (1/4" external hexagon to 1/4" external square head), one magnetic 899/4/1 bit holder for screwdriver machines, 9 BiTorsion bits (BTZ) with 1/4" external hexagon drive for Phillips-head screws, TORX®, slotted and square head, 4 tough bits (Z) for hexagonal socket (imperial sizes), 4 Zyklop 8790 HMA sockets (imperial sizes), 1/4". In the compact Tool-Check Modular 1. Tools can be connected to other components of the Tool-Check Modular system using the rigid Tool-Check Modular adapter 9549 or the flexible Tool-Check Modular hinge 9550.
__#Product Specifications
Highlights
- Tool-Check Modular: individual combination of different Tool-Check Modular components
- Very compact 21-piece tool set for manual and machine-operated screwdriving
- Perfect for a wide variety of screw connectio ns with ¼" ratchet, hand or machine
- Multi-component Kraftform handle with mounting for 1/4" hex drive bits
- 1/4" 8011 Zyklop Mini 4 bit ratchet for handles with 1/4" bit mounting
- Magnetic 899/4/1 K bit holder for 1/4" hex drive bits; and machine use
- 9 BiTorsion bits (BTZ) for Phillips, TORX®, slotted and square head, 4 tough bits (Z) for hexagonal socket screws; 25 mm and 50 mm length
- 4x 8790 HMA sockets, 1/4", imperial sizes; one adapter 1/4" external hexa gon to 1/4" external square head
Drive Types
- Square socket
- Phillips
- TORX®
- Slotted
- Hexagon
- Square Recess
- External Hexagon
Product Features
- Modular S
- Kraftform handle
- Non-roll feature
- Drop-forged full steel design
- Return angle 6°
- Take it easy socket
- BiTorsion
- Take it easy bits
- Hex-Plus
- Switch
__#What's Included
- 815/1 Bitholding screwdriver - 1/4" x 92 mm - qty 1 - part# 05145100001
- 8011 Zyklop Mini 4 Bit ratchet, 1/4" - 1/4" x 50 mm - qty 1 - part# 05003662001
- 870/1 Adaptor - 1/4" x 25 mm - qty 1 - part# 05136000001
- 899/4/1 U niversal Bit Holder - 1/4" x 50 mm - qty 1 - part# 05053457001
- 851/4 BTZ bits - PH 1 x 50 mm - qty 1 - part# 05059550001
- 851/4 BTZ bits - PH 2 x 50 mm - qty 1 - part# 05059552001
- 867/1 BTZ TORX® bits - TX 10 x 25 mm - qty 1 - part# 05066120001
- 867/1 BTZ TORX® bits - TX 15 x 25 mm - qty 1 - part# 05066122001
- 867/1 BTZ TORX® bits - TX 20 x 25 mm - qty 1 - part# 05066124001
- 867/1 BTZ TORX® bits - TX 25 x 25 mm - qty 1 - part# 05066126001
- 800/4 BTZ bits - 0.8 x 5.5 x 50 mm - qty 1
- 840/1 Z bits - 3/32" x 25 mm - qty 1 - part# 05135072001
- 840/1 Z bits - 1/8" x 25 mm - qty 1 - part# 05135073001
- 840/1 Z bits - 5/32" x 25 mm - qty 1 - part# 05135074001
- 840/1 Z bi ts - 3/16" x 25 mm - qty 1 - part# 05135075001
- 868/4 BTZ Square-Plus bits - # 1 x 50 mm - qty 1 - part# 05060147001
- 868/4 BTZ Square-Plus bits - # 2 x 50 mm - qty 1 - part# 05060148001
- 8790 HMA Zyklop 1/4" socket - 3/8" x 23 m m - qty 1 - part# 05003520001
- 8790 HMA Zyklop 1/4" socket - 7/16" x 23 mm - qty 1 - part# 05003521001
- 8790 HMA Zyklop 1/4" socket - 1/2" x 23 mm - qty 1 - part# 05003522001
- 8790 HMA Zyklop 1/4" socket - 9/16" x 23 mm - qty 1 - part# 05003523001
