Description
9-piece tool set for the proper assembly and disassembly of tyre pressure control systems. Comes with torque technology for controlled screw tightening. Hand tool with multi-component Kraftform handle for high working speeds and ergonomic working. Two pre-set tools to connect the union nut with the screw and to fasten the sensor component to the valve. An adjustable Kraftform pistol handle for torque values of between 4.0 and 8.8 Nm. Two TX bits with holding function, socket adaptor, two sockets plus a valve dolly (for applications up to 4.5 Nm). Suitable for tyre control, systems from e.g. Schrader®, Alligator®, VDO®.
__#Product Specifications
Highlights
- Assembly set for tyre pressure control systems
- To monitor the tyre pressure on motor vehicles
- Optimum tyre pressure saves fuel and prevents tyre wear
- 9-piece set in a stable plastic case
Drive Types
- Hexagon
- TORX®
- Square socket
- Square Recess
- External Hexagon
- Awl
Product Features
- Torque
- Adjustable
- Pre-set
- Kraftform handle
- No n-roll feature
- HF - With holding function
- Bit handholder with Rapidaptor quick-release chuck
__#What's Included
- 7400 series Kraftform Torque screwdrivers, with factory pre-set value (0.3-3.0 Nm) and Rapidaptor quick-release chuck, handle size 105 mm - 7461 x 1.2 Nm x 1.2-3.0 Nm - qty 1 - part# 05074716001
- Series 7400 Kraftform pistol handle, ad justable torque screwdrivers (3.0-8.8 Nm) with Rapidaptor quick-release chuck - 7443 x 4.0-8.8 Nm - qty 1 - part# 05074705001
- 300 TX TORX® Torque-indicator - TX 10 x 1.4 Nm - qty 1
- 870/1 Adaptor - 1/4" x 25 mm - qty 1 - part# 05136000 001
- 790 A/50 Nut Spinner Socket - 11 x 50 mm - qty 1
- 790 A/50 Nut Spinner Socket - 12 x 50 mm - qty 1
- 867/4 TORX® HF bits with holding function - TX 15 x 50 mm - qty 1
- 867/4 TORX® HF bits with holding function - TX 20 x 50 mm - qty 1
- 327 Valve Holder - 32 x 70 mm - qty 1 - part# 05160111001
