The 3-jaw, spark-free tab pullers with oscillating and reversible jaws 202-1-F are used for centric extraction of bearings, gears, and discs in all common sizes for crafts, workshops, and industry. Due to their construction from high-quality special alloys such as copper-beryllium or aluminum-bronze, spark-free pullers are particularly suitable for use in explosive environments, as they do not generate sparks even when in mechanical contact with metal surfaces. The oscillating jaws with adjustable reach can be used on both sides, offering maximum flexibility during extraction. The 3-jaw configuration guarantees even load distribution, ensuring a particularly secure grip on the part being extracted.
Article features
 Version low spark |
 Spread external extraction (min. - max.) [mm/inch] |
 Reach external extraction [mm/inch] |
 Wrench size actuation hexagon [mm/inch] |
Max. torque [Nm/ft lb] |
Claw end with slit |
Max. tensile force [kN] |
 Max. tension force [t/US t. sh.] |
Gross weight [kg/lb] |
 Carbon footprint [kg CO₂e] |
FWI seal of origin "Made in Germany" |
|---|---|---|---|---|---|---|---|---|---|---|
| Yes |
0 - 150 mm / 0 - 5 7/8 in |
85 mm / 3 3/8 in |
17 mm / 11/16 in |
75 Nm / 55.32 |
No | 50 kN |
3 t / 3.31 |
6,775 kg / 14.939 |
7.66 | ✓ |
