Description
The sentence jaws with adjustable reach is suitable for 3-jaw universal pullers with pivoting jaws and adjustable reach of series 205. The robust jaws ensure a particularly safe removal of bearings, gears, and discs.
Application
For 3-jaw universal pullers with swiveling jaws and adjustable reach of series 205Article features
 Reach external extraction [mm/inch] |
 Overall length [mm/inch] |
 Total jaw thickness (L+1 mm) (jaw distance to base surface) [mm/inch] |
 Overall jaw's hooked claw depth (overall claw depth H) [mm/inch] |
 jaw's hooked claw width (jaw spread J) [mm/inch] |
 Usable jaw's hooked claw reach (usable claw reach O) [mm/inch] |
 Jaw's hooked claw thickness at the tip (claw thickness K) [mm/inch] |
Gross weight [kg/lb] |
 Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|---|
|
220 mm / 8 11/16 in |
270 mm / 10 5/8 in |
18 mm / 11/16 in |
50 mm / 1 15/16 in |
24 mm / 15/16 in |
15 mm / 9/16 in |
4 mm / 3/16 in |
2,25 kg / 4.961 |
2,95 |
