Description
Description
The 3-jaw universal puller with extremely narrow, quickly adjustable jaws and trapezoidal support surfaces at the claw is used for the safe and user-friendly removal of gearbox gears, bearings, pinions, synchronizers, and similar components. This allows any component that is seated on a shaft and is freely accessible from the outside to be removed. The trapezoidal support surfaces of the claw ensure that very tight and hard-to-reach gaps are also accessible. The 3-jaw design guarantees an even load distribution and thus a particularly secure grip on the part being removed.
Application
For the safe and user-friendly removal of gear wheels, bearings, sprockets, synchronizers, and similar components.Article features
 Spread external extraction (min. - max.) [mm/inch] |
 Reach external extraction [mm/inch] |
 spread internal extraction (min. - max.) [mm/inch] |
 Wrench size actuation hexagon [mm/inch] |
Max. torque [Nm/ft lb] |
Max. tensile force [kN] |
 Max. tension force [t/US t. sh.] |
Gross weight [kg/lb] |
Included in the set |  Carbon footprint [kg CO₂e] |
|---|---|---|---|---|---|---|---|---|---|
|
13 - 130 mm / 1/2 - 5 1/8 in |
100 mm / 3 15/16 in |
70 - 180 mm / 2 3/4 - 7 1/16 in |
17 mm / 11/16 in |
40 Nm / 29.50 |
30 kN |
3 t / 3.31 |
1,535 kg / 3.385 |
K-2030-10+S-T | 2,01 |
